WiFi temperature data logger with free web cloud server

System Feature

• Cortex M3 32-bit ARM
• Reliable performance with built-in double watchdog, 24×7 operation
• Support signal fileter
• Stable reconnection strategy for data transmit
• Update RTC automatically or manually, clock source support Sms, NTP, CwtIO Server
• Automatically execute preset task by schedule(second, minute, day, week, month)
• Event-based linkage programming, e.g. alarm linkage output
• Provide console utility for visual programming over 100 parameters
• Optional inside lithium battery for power lost alarm and keep 8-20 hours working

DI feature

• Monitor dry contact(NO or NC)

DO(T) feature

• Open-collector output(drive voltage=power supply voltage, Drive current≤500mA)
• Remote or local event activate DO on/off/pulse
• Remember status when power lost

DO(K) feature

• Relay output(NO, contact load: 2A / 125VAC,220VDC)
• Remote or local event activate DO on/off/pulse
• Remain down status when power lost

AI feature

• Accept 4-20mA (option: 0-5V), Sampling frequency: 33Hz, 10-bit precision)
• Convert signal to actual measure value,support adjustment
• Can set parameters for value processing, alarm, data transmission
• Signal lost alarm

SMS feature

• Support 10 cell phone numbers for alarm and control
• Sms alarm when any IO channel triggered or out of preset normal range
• Editable alarm and recover sms with time stamp
• Query any IO channel’s status or value via sms command
• On/off/pulse output by sending sms
• Configurable schedule for sms report IO channel's status or value
• Remote update parameters by sms
• Sms remind for sim card overdue
• Sms alar for power lost and recover

Wireless network communication

• Option network: cellular(2g/3g/4g) or Wi-Fi
• TCP/IP connect at most 4 servers(support Static IP address or domain)
• Support post or respond mode for data communication
• Communicate with server by optional Cwt_IO, Modbus TCP, http post protocol
• Can forward data between wireless network with RS485 or RS232

Modbus feature

• polling salve over RS485 with modbus rtu protocol
• Can be a I O module to be read/write by modbus master
• Run Modbus RTU or TCP protocol over GPRS/3G

TI feature

• Can set high or lower level to alarm, data log via wireless network
• Fahrenheit or centigrade units for temperature
• Detect probe connect or disconnect to alarm

Wireless Remote Monitoring Solutions

Whatever term you use for Telemetry, whether it's remote monitoring, M2M, Machine2Machine, Machine2Man or even Man2Machine then CWT wire free telemetry products will serve you well. Our Telemetry Solutions have been designed with the user in mind, so they are cost-efficient, easy to configure and install.

We can interface to machines in different ways, whether it be via process signals, or serial communications, including Modbus.

Benefits of Telemetry

This ‘Internet of Things’ telemetry technology offers rapid payback, delivering operational, environmental and financial benefits, from cutting delivery miles, to reacting in good time to warnings of machinery breakdown, leakage, theft, run-outs and safety breaches.

Why choose CWT

CWT award-winning Telemetry Solutions are proven globally, in a range of sectors including chemical & petrochemical, food distribution and production, transport, water & waste, environmental and factory automation.

“We were looking for a robust telemetry system and platform to replace our infield monitoring and critical remote alarm equipment. We picked Powelectrics as our preferred supplier and Metron View as our new solution to replace all our infield remote monitoring and alarm systems. Working with the Powelectrics Team is a real breath of fresh air, they listen to our needs, help us with our challenges and provide a really robust solution. They are flexible and understanding – we are quite demanding! We wouldn’t hesitate to recommend them and their solutions – a great company to partner with for our critical system needs.” Technical Manager
