wifi sensor data logger, pc based data acquisition system

System Feature

• Industrial NXP 32-bit ARM MCU
• Reliable performance with built-in double watchdog, 24×7 operation
• With signal filtering mechanisms
• Support automatic network reconnection and data re-send
• Automatically or manually update interior clock by sms or NTP or server
• Configurable action schedule(second, minute, day, week, month)
• Support Interlock programming, Event trigger
• Provide configure software, visual programming, over 100 parameters can be set
• Optional inside battery that life is 8-20 hours, cellular module Intelligent sleep when power lost

DI feature

• Trigger dry contact(NO or NC)

DO(T) feature

• Open-collector output(drive voltage=power supply voltage, Drive current≤500mA)
• DO can be activated by remote or local schedule
• Status memory function for power lost

DO(K) feature

• Relay output(NO, contact load: 2A / 125VAC,220VDC)
• on/off/pulse DO by remote control or local event
• Remain down status when power lost

AI feature

• 4-20mA (option: 0-5V) in, Sampling frequency: 33Hz, 10-bit precision)
• Convert signal to actual measure value,support adjustment
• Can set parameters for value processing, alarm, data transmission
• Signal lost alarm

SMS feature

• Preset 10 phone numbers (support distribute authority to receive sms)
• Sms alarm when any IO channel triggered or out of preset normal range
• Customizable sms messages, like alarm, receove, report
• Query any IO channel’s status or value via sms command
• On/off/pulse output by sending sms
• Configurable schedule for sms report IO channel's status or value
• Remote setting via sms commands
• Sms remind for sim card overdue
• Power lost and recover alarm by sending sms

Wireless network communication

• With 2g, 3g, 4g, Wi-Fi version
• TCP/IP connect at most 4 servers(support Static IP address or domain)
• Automatically Upload data when alarm or according to schedule
• Communication protocol: Modbus TCP,http post, Cwt_IO(two-way communication)
• Support two-way data transparent transmission with RS485 or RS232

Modbus feature

• polling salve over RS485 with modbus rtu protocol
• As a RS485 I O module to be polled by modbus master
• Support Modbus RTU to TCP convert over Ethernet or GPRS/3G

Wireless Remote Monitoring Solutions

Whatever term you use for Telemetry, whether it's remote monitoring, M2M, Machine2Machine, Machine2Man or even Man2Machine then CWT wire free telemetry products will serve you well. Our Telemetry Solutions have been designed with the user in mind, so they are cost-efficient, easy to configure and install.

We can interface to machines in different ways, whether it be via process signals, or serial communications, including Modbus.

Benefits of Telemetry

This ‘Internet of Things’ telemetry technology offers rapid payback, delivering operational, environmental and financial benefits, from cutting delivery miles, to reacting in good time to warnings of machinery breakdown, leakage, theft, run-outs and safety breaches.

Why choose CWT

CWT award-winning Telemetry Solutions are proven globally, in a range of sectors including chemical & petrochemical, food distribution and production, transport, water & waste, environmental and factory automation.

“We were looking for a robust telemetry system and platform to replace our infield monitoring and critical remote alarm equipment. We picked Powelectrics as our preferred supplier and Metron View as our new solution to replace all our infield remote monitoring and alarm systems. Working with the Powelectrics Team is a real breath of fresh air, they listen to our needs, help us with our challenges and provide a really robust solution. They are flexible and understanding – we are quite demanding! We wouldn’t hesitate to recommend them and their solutions – a great company to partner with for our critical system needs.” Technical Manager
